The real bed dimensions, payload and wheel-arch clearances for the Next-Gen Ford Ranger — and exactly what overland gear you can load. Below is a to-scale 3D model of the bed, built from measured data.
Drawn to scale from measured bed dimensions.
Measured cargo-area dimensions for the Next-Gen Ranger (P703, 2022–). Every gear-fit call on this page is computed from these.
Dimensions are approximate and sourced from measured references — verify against your exact model year and trim before purchasing gear. Payload includes passengers and accessories; check your door-jamb sticker.
A realistic overland load against the Ranger's 1060 kg (2,337 lb) payload budget — the highest of any mid-size truck here.
The Kitchen Cube is a modular, aircraft-grade aluminum camp kitchen that packs down to a compact 12-inch (305 mm) cube to live in your truck bed, and deploys on the tailgate.
Join the Waitlist →Exact fitment specs ship with the waitlist. Coming 2026.
The Next-Gen Ranger (P703, 2022–) bed measures about 1549 × 1560 × 506 mm (61.0 × 61.4 × 19.9 in), with roughly 1155 mm (45.5 in) of flat floor between the wheel arches.
About 1,060 kg (2,337 lb) — the highest of any mid-size pickup here, and higher than a base F-150. Includes passengers and accessories; check the door-jamb sticker.
Yes — 445–935 mm fridges against 1549 mm of bed, drawers up to about 1155 mm wide on the flat floor, and the lowest arches of any mid-size truck here at ~185 mm (7.3 in).
Yes — the 12-inch (305 mm) packed cube sits on the flat floor with about 201 mm (7.9 in) left below the bed rail. Join the waitlist for early access.
